XRAY SHARK® XD80

  • X-ray inspection for packaged food or non-food products
  • Detects high density materials like metal, ceramic, stone or plastic
  • Easy operation with autocalibration and clearly arranged functions on 17“ touchscreen
  • XIA software for instant analysis and detection with high accuracy and reliability
  • Single or dual beam for optimized inspection of different product sizes and materials
XRAY SHARK® XD80

Features

  • Real time detection with coloured contamination analysis
  • Functions for masking of product parts for better detection of contamination
  • Autosaving of inspection data with time and date stamp
  • User-friendly operation in daily business with 255 pre-set products
  • USB and Ethernet for data transfer to PC or memory stick
  • Single beam or dual beam available
  • Hygienic and easy to open product tunnel for easy cleaning and maintenance
  • Built-in remote control and maintenance
  • 24 hours non-stop operation
  • Reliable German safety standard - TÜV-certificate available

Function

The XD80 is particularly suitable for packaged food or non-food products, for example in plastic packaging, jars, cartons and even metal foil or metal cans. Unwanted foreign objects such as metal, stones, ceramics or plastic with high density in the product are detected. The hygienic design allows easy cleaning and maintenance of the device. This makes the XD80 particularly suitable for all companies and industries that have to ensure high hygiene standards.

Delivery Scope

  • Xray Scanner with image processing software XIA
  • Complete protection against radiation
  • Certified test cards with soda lime glass, ceramics, steel spheres in various diameters

Specifications

Model Name/ID XD80-H2 (former XBD85+)
X-Ray Source Dual beam x-ray generator with max. 80kV (2x480W), variable in voltage + current
Radiation Leakage 3 µSv/h or less, at using all safety devices
Safety X-ray protective curtains (lead-free) – quickly detachable, magnetic safety switches at cabinet doors and tunnel hatches, emergency stop push button, emergency stop in/out interfaces to safety circuits of production line, X-ray off key switch
X-Ray View 2x top down
Cooling Highly efficient, silent DC filter fans
Housing Finish Stainless steel grade AISI 304 / DIN EN 1.4301 (X5CrNi18-10)
Protection Type IP54 (according to IEC 60529), including touch panel and fans
Conveyor Type Polyurethane belt white, food grade
Belt Width 800 mm
Scanning Height ----
Scanning Width 800 mm
Conveyor Speed Conveyor speed by product, 0.05 to 0.98 m/sec (7 fixed speed steps)
Max Product Dimensions width x height: 800 x 800 mm
Max Product Weight 50 kg total weight
Available Reject Method Additional conveyor with transversal pusher
Product Memory 255 different product set-ups
Display 17“ color-TFT capacitive touchscreen
Inspection Features Autocalibration, auto adaption to density distribution, density, hard contrast, soft contrast, masking technology, SuperContrast, SizeFilter, AutoEdge masking, images AutoSave/Load, Multi Segment Inspection, metal can and foil inspection, fill quantity, generator energy by product, password protection
In/Outputs Programmable outputs (contamination, ready, Emergency OFF) Programmable inputs (Emergency OFF, wake up, optional control signals)
Data Transfer and Reporting Ethernet for remote support via internet, USB for external keyboard/ mouse/ memory stick
Weight estimated 1.7 t
Power Supply 1ph, 230 VAC +/- 10%, 50/60 Hz, 2.0 kW full operation
Compressed Air Supply without pusher 0 (zero) bar/psi with optional pusher system minimum 4 bar/58 psi
Environmental Conditions 10° to +30°C / 50°F to 86°F, with relative humidity max 90%, non-condensing,external cooling device recommendend/needed
Conformity CE, compliant to german x-ray regulations, specific adaptation for other countries
X-Ray Detector Low noise 816 mm line scan CCD, diode pitch 0.8 mm or 0.4 mm (optional)
